       Compoarison of Physical
       properties with other Metals

TITANIUM'S CHEMICAL & MECHANICAL PROPERTIES
Quality   Gr 1 Gr 2 Gr 4 Gr 5 Gr 7 Gr 9 Gr 11 Gr 12
Analysis% Fe max 0.2 0.3 0.5 0.4 0.3 0.25 0.2 0.3
  O max 0.18 0.25 0.4 0.2 0.25 0.15 0.18 0.25
  N max 0.03 0.03 0.05 0.05 0.03 0.02 0.03 0.03
  C max 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
  H max 0.015 0.015 0.015 0.015 0.015 0.015 0.015 0.015
  pd         0.12-0.25   0.12-0.25
  Al       5.5-6.7   2.5-3.05
  V       3.5-4.5   2.0-3.0
  Mo       3.5-4.5   2.0-3.0   0.4-0.4
Yield
Strength
N/㎟
RP 0.2 170-310 275-450 483.-655 828- 275-450 483- 170-310 345-

Tensile
Strength
 N/㎟

Rm min 240 345 550 895 345 620 240 483
Hardness Vickers 140 170 310 330 170 250 140 170
Elongation 5 x d 24 20 15 10 20 15-17 24 18
